Eagle Eye SLB-240-200 240 VDC, 0-200 Amp Battery Load Bank
$11,655.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Eagle Eye SLB-240-200 240 VDC, 0-200 Amp Battery Load Bank Specs
| Cell Voltage | Standard DAC: 1.2V1, 2V, 6V, 12V / Optional: Custom DAC configurations available upon request |
| Discharge Current Range | Single Load: 12 – 600A / Parallel Load: Up to 1200A |
| Discharge Voltage Range | Range: 10 – 576V (Max) / Voltage Steps: 12V, 24V, 36V, 48V, 80V, 125V, 240V, 380V, 480V |
| Accuracy | Discharge Current: 1% / Voltage: 0.5% – 0.8% |
| Resolution | Discharge Current: 0.1 A or 0.5% / Voltage: 0.001 V |
| Sampling Interval | 5 seconds – 1 minute |
| Data Transfer | USB, Wireless (466 MHz) |
| Display | Backlit LCD |
| Operating Environment | 0 – 40 °C (32 – 104 °F) |
| Power Requirements | 110/220 VAC 50/60 Hz / DC (from connected batteries) |
| Dimensions | Small: 400 x 177 x 288 mm (15.7 x 7 x 11.3 in) Medium: 520 x 202 x 355 mm (20.5 x 8 x 14 in) Large: 555 x 225 x 435 mm (22.5 x 8.9 x 17.2 in) X-Large: 603 x 400 x 740 mm (23.7 x 15.7 x 29 in) XX-Large: 762 x 406 x 737 mm (30 x 16 x 29 in) |
| Weight | Small: 11 kg (24 lbs) Medium: 16 kg (36 lbs) Large: 21 kg (47 lbs) X-Large: 42 kg (93 lbs) XX-Large: 55 kg (122 lbs) |
- SLB-Series Load Bank
- DataView Management Software
- Carrying Case (for small & medium size models)
- Set of 3m/10ft Load Cables
- 3m/10ft Voltage Test Leads
- PC communication interface
- Ground Cable
- AC Power Cord
- USB Drive with Software/
- User Manual
- (2) Antenna
- Optional: Standard DAC Package
- Optional: CT Clamp forAssisted or External Load Testing
- Optional: Parallel Load Cable
