Binder World UFV500UL-120V – Ultra Low Temperature Freezer, -90 to -40 deg C, 477 L, 120 V
$10,783.00
In Stock
Advanced medical compound sample collection loops reach absolute stability when using the Binder World UFV500UL-120V ultralow deep freezer. This 477 L upright storage apparatus safely locks analytical materials down into a -90 to -40 °C control parameter. It operates efficiently through a standard 120 V industrial line to maximize compressor life.
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Binder World UFV500UL-120V - Ultra Low Temperature Freezer, -90 to -40 deg C, 477 L, 120 V Specs
| Description | UFV500-230V-W |
| Option Model | Water cooling |
| Article Number | 9020-0349 |
| Cooling down time from 22 °C to -80 °C [min] | 360 |
| Temperature fluctuation at -80 °C [± K] | 1.5 |
| Temperature range | -90…-40 |
| Temperature variation at -80 °C [± K] | 2.5 |
| Warm-up time during power failure from -80 °C / -122 °F to -60 °C / -76 °F [min] | 230 |
| Nominal power [kW] | 1.6 |
| Phase (Nominal voltage) | 1~ |
| Power frequency [Hz] | 50 |
| Rated Voltage [V] | 230 |
| Unit fuse [A] | 10 |
| Unit doors | 1 |
| Depth net [in] | 36.96 |
| Height net [in] | 77.5 |
| Width net [in] | 32.54 |
| Depth [in] | 23.84 |
| Height [in] | 51.2 |
| Width [in] | 23.88 |
| Interior volume [cu.ft.] | 16.8 |
| Net weight of the unit (empty) [lbs] | 545 |
| Permitted load [lbs] | 441 |
| Permitted load of individual compartment [lbs] | 110 |
| Wall clearance back [in] | 3.94 |
| Wall clearance sidewise [in] | 9.85 |
| Energy consumption at set-point -80 °C and ambient temperature = 21 °C [kWh/d] | 7.9 |
| Sound-pressure level [dB(A)] | 47 |
| Number of shelves (std./max.) | 3/13 |
| Cryoboxes, 50 mm | 352 |
| Freezer racks per compartment | 4 |
