TPI 708A740 – Combustion Analyzer Kit with Printer
$428.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
TPI 708A740 - Combustion Analyzer Kit with Printer Specs
| Specifications | TPI 708A740 Combustion Analyzer Kit with Printer |
| Gases | Range |
| Oxygen | 0-25% |
| Carbon Monoxide | 0-10,000 ppm |
| Carbon Dioxide | 0-25% |
| CO/CO2 Ratio | 0-0.999 |
| Combustion Eff. | 0-100% |
| Input Type | K-Type thermocouple |
| Range | -58°F to 1832°F (-50°C to 1000°C) |
| Resolution | 1°F (1°C) |
| Accuracy | +/- (0.3% of rdg + 2°F) or +/- (0.3% of rdg + 1°C) |
| Operating Temperature Range | 14°F to +122°F (-10°C to +50°C) |
| Battery / Batery Life | AA (3) / > 6 Hours |
| Fuels | Natural Gas, LPG, Light Oil, Heavy Oil, Bituminous Coal, Anthracite Coal, Coke, Butane, Wood, Bagasse |
| Display | 3 Line Backlit LCD w/ annunciators |
| Data Storage | 50 sets of readings |
| Time & Date | 24 Hour Real Time Clock |
| Dimensions | 7.8” x 3.5” x 2.4” |
| Weight | 1.1lbs |
| Specifications | TPI A740 Infrared Printer |
| Maximum Transmitting Distance | 18 inches (45cm) |
| Maximum Horizontal Receiving Angle | ±30° |
| Vertical Receiving Angle | -10° to + 20° |
| Battery Power | 4 x 1.5V Alkaline battery |
| Adapter | DC 7V / 1500mA, 50Hz, 240V (CE) DC 9V / 1A, 60Hz, 120V (CUL) |
| Paper | A746 |
| Operating Temperature | 32° to 122°F (0° to 50°C) |
| Operating Humidity | 5% to 80% RH |
| Storage Temperature | 14° to 140°F (-10° to 60°C) |
| Feature / Combustion Analyzer Model | 708 |
| O2 | 0 to 25% |
| CO | 0 to 10000 ppm |
| CO2 | 0 to 25% |
| NO | 0 to 5000 ppm |
| NOX | 0 to 5250 ppm |
| CO2 Ratio | 0 to 25% |
| Excess air | Yes |
| Efficiency (gross and net) | Yes |
| Temperature | Yes |
| Temperature rise | Yes |
| Built in manometer | No |
| Internal NoX filter | Yes |
| Printer (optional) | IR |
| External oil filter | Optional |
| 1 ppm CO resolution for BPI | Yes |
| Residential, commercial, industrial | Yes |
| PC Compatible | No |
| LCD Display | Yes |
| Smart Sensors (field replaceable) | No |
| Onboard memory | 50 tests |
| Backlight | Yes |
| Battery power | Alkaline |
- Infrared printer (A740);
- Rubber Boot (A765);
- Soft Carrying Case (A768);
- Flue Sampling Probe (A770);
- In-Line Filter assembly installed on Flue probe (A794);
- Temperature Probe (GK11M);
- Mini Pump Protection Filter Assembly and spare filters (A763);
- Exhaust Spigot (removable) (A764);
- Instruction Manual;
