Keithley 7707 – 32-channel Digital I/O Module
$969.00
In Stock
The Keithley 7707 digital interface card expands automated testing racks by blending a 32-channel digital I/O network with a 10-channel multiplexer system. This dual-purpose acquisition board drives external logic circuit relays while measuring analog voltage lines cleanly. It features high sink currents up to 300mA to actuate heavy industrial components.
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Keithley 7707 - 32-channel Digital I/O Module Specs
| CHANNELS 1–10: | Multiplex one of 10 2-pole or one of 5 4-pole signals into DMM. |
| CHANNELS 11–14: | 32 Digital Inputs/Outputs referenced to chassis ground. |
| THERMAL PROTECTION: | Channels 11–14 are thermally protected to 1A. |
| MAXIMUM SIGNAL LEVEL: | Any Channel to Any Channel (1–10): 300VDC or 300Vrms (425V peak) for AC waveforms, 1A switched, 60W, 125VA maximum. |
| SAFETY CATEGORY: | Conforms to European Union Directive 73/23/EEC EN 61010-1, CAT I. |
| CONTACT LIFE (typ): | >10 5 operations at max. signal level; >10 8 operations no load 1 . 1 Minimum signal level 10mV, 10µA. |
| CONTACT RESISTANCE: | <1Ω any path and additional 1Ω at end of contact life. |
| CONTACT POTENTIAL: | <6µV typical per contact pair and additional 5µV with Channels 11–14 at rate VOUT(L). |
| OFFSET CURRENT: | <100pA |
| CONNECTOR TYPE: | 50-pin male D-shell, Channels 11–14. 25-pin female D-shell, Channels 1–10. Supplied with female and male IDC ribbon cable connectors. |
| ISOLATION BETWEEN ANY TWO TERMINALS: | >10 9 Ω, <100pF with isolation channels 16 and 17 open |
| ISOLATION BETWEEN ANY TERMINAL AND EARTH: | >10 9 Ω, <200pF. |
| CROSS TALK (10 MHz, 50Ω Load): | <–35dB |
| INSERTION LOSS (50Ω Source, 50Ω Load): | <0.1dB below 1MHz. <3dB below 2MHz. |
| COMMON MODE VOLTAGE: | 300VDC or 300Vrms (425V peak) for AC waveforms between any terminal and chassis. |
| VIN(L): | <0.8V (TTL). |
| VIN(H): | >2V (TTL). |
| VOUT(L): | <1.0V @ Iout = 100mA. |
| VOUT(H): | >2.4V @ out = 1mA. |
| VOUT(H))MAX.: | <40V with external open drain pull-up. |
| READ/WRITE SPEED: | 50/s. |
| 10 CHANNELS: | 10 channels of 2-pole relay input All channels configurable to 4-pole. |
| RELAY TYPE: | Latching electromechanical |
| ACTUATION TIME: | <3ms. |
| FIRMWARE: | Specified for Model 2700 rev. A02 or B01, 2701 rev. A01, and 2750 rev. A01 or higher. |
| Model 2700: | (1) 7707 and (1) 77xx, except 7706. |
| Model 2701: | Any combination of 77xx modules. |
| Model 2750: | (4) 7707 and (1) 77xx, except 7706. A 7706 module may be substituted for a 7707 module. |
| OPERATING ENVIRONMENT: | Specified for 0° to 50°C. Specified to 50% R.H. at 35°C. |
| STORAGE ENVIRONMENT: | –25°C to 65°C. |
| WEIGHT: | 0.5kg (1.1 lbs). |
- 7707-306A - 50-pin D-Sub Female IDC Connector Kit
- 7709-307A - 25-pin D-Sub Male IDC Connector Kits
