Rigol MC3648 MATRIX Module
$337.00
In Stock
The Rigol MC3648 matrix module drives high-performance routing layouts across complex electronic automated test systems. This specialized data acquisition hardware sets up a versatile 4 x 12 grid config, tracking up to 48 2-wire cross-points cleanly. Engineers rely on its fast mechanical switching arrays to handle precise signal distribution tasks.
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Rigol MC3648 MATRIX Module Specs
| Multiplexer | Actuator |
| General | MC3132 |
| Number of Channels | 32 |
| 2/4 wire | 2 wire |
| Connect to DMM Module? | Yes |
| Scanning Speed [1] | 60Ch/s |
| Open/Close Speed | 200Ch/s |
| Voltage (DC, AC rms) | 300Vrms |
| Current (DC, AC rms) | 1Arms |
| Power (W, VA) | 50VA |
| Isolation (ch-ch, ch-earth) (DC, AC rms) | 300Vrms |
| Offset Voltage | 5uV |
| Initial Closed Channel Resistance | <1Ω |
| Isolation (ch-ch, ch-earth) | >10GΩ |
| Bandwidth | 1MHz |
| Ch-Ch Cross Talk (dB) [2] 1MHz | -45 |
| Capacitance HI-LO | 100pF |
| Capacitance LO-Earth | 200pF |
| Volt-Hertz Limit | 10 8 |
| T/C Cold Junction Accuracy (Typical) | 0.8°C |
| Switch Life (No Load) (Typical) | 100M |
| Switch Life (Rated Load) (Typical) [5] | 100K |
| Operating Temperature | 0°C - 55°C |
| Storage Temperature | -20°C – 70°C |
| Humidity (non-condensing) | 40°C / 80% RH |
