Fluke 87V/E2 Industrial Electrician Combo Kit
Description
Description
The Fluke 87-5/E2 industrial electrician combo kit includes the Fluke 87V multimeter which has improved measurement functions, trouble-shooting features, resolution and accuracy to solve more problems on motor drives, in plant automation, power distribution and electro-mechanical equipment. The Fluke 87V operates very similar to the classic 87, but with more problem-solving power, safety, convenience and impact protection.
Fluke 87V multimeters feature a unique function for accurate voltage and frequency measurements on adjustable speed motor drives and other electrically noisy equipment. The Fluke 87V also has a built-in thermometer which conveniently allows you to take temperature readings without having to carry a separate instrument. The large digit display with bright, two-level backlight makes the 80 series V significantly easier to read than older models.
All inputs are protected to Category III, 1000V and Category IV 600 V. They can withstand impulses in excess of 8,000 V and reduce risks related to surges and spikes.
Fluke 87-5/E2 Kit Contents
- 87V multimeter
- TL224 silicone test leads
- AC220 long-reach alligator clips
- TP238 test probes
- TPAK ToolPak magnetic meter hanging kit
- 80BK temperature probe
- Holster
- 9V battery (installed)
- Getting started manual
- CD with detailed manual
Fluke 87V/E2 Industrial Electrician Combo Kit Specs
| Ranges | DC Voltage: 600.0mV, 6.000V, 60.00V, 600.0V, 1000V |
| AC Voltage | 600.0mV, 6.000V, 60.00V, 600.0V, 1000V |
| Resistance | 600.0Ω, 6.000kΩ, 60.00kΩ, 600.0kΩ, 6.000MΩ, 50.00MΩ |
| DC Current | 600.0μA, 6000μA, 60.00mA, 600.OmA, 6.000A, 10.00A |
| AC Current | 600.0μA, 6000μA, 60.00mA, 600.OmA, 6.000A, 10.00A |
| Frequency | 199.99Hz, 1.9999kHz, 19.999kHz, 199.99kHz |
| Capacitance | 10.00nF, 100.0nF, 1.000μF, 10.00μF, 100.0μF, 9,999μF |
| Temperature | -200°C to +1090°C (-328°F to +1994°F) |
| Feature | True-RMS AC voltage and current |
| Feature | 0.05% DC accuracy |
| Feature | 4.5 digit mode for precise measurements |
| Feature | Min/Max and average recording |
| Feature | Category III, 1000 V and Category IV, 600 V |
