Mark-10 M7-200 - Digital Force Gauge 200 lbF / 1000 N, 110V
Mark-10 M7-200 - Digital Force Gauge 200 lbF / 1000 N, 110V - Image 2
Mark-10 M7-200 - Digital Force Gauge 200 lbF / 1000 N, 110V - Image 3
Mark-10 M7-200 - Digital Force Gauge 200 lbF / 1000 N, 110V - Image 4
Mark-10 M7-200 - Digital Force Gauge 200 lbF / 1000 N, 110V - Image 5

Mark-10 M7-200 – Digital Force Gauge 200 lbF / 1000 N, 110V

$1,297.00
In Stock
In Stock
Add to wishlist
Commercial Pricing
Request for Quotations for Bulk Orders
SKU: Mark-10-M7-200
Category:
Brand:

Mark-10 M7-200 - Digital Force Gauge 200 lbF / 1000 N, 110V Specs

SeriesM7-0125
Capacity X Resolution lb0.12 x 0.00002 lb
Capacity X Resolution oz2 x 0.0005 oz
Capacity X Resolution kg-
Capacity X Resolution g50 x 0.01 g
Capacity X Resolution N0.5 x 0.0001 N
Capacity X Resolution kN-
Capacity X Resolution mN500 x 0.1 mN
Accuracy±0.1% of full scale
Sampling rate14,000 Hz
PowerAC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low.
Battery LifeBacklight on: up to 7 hours of continuous use    Backlight off: up to 24 hours of continuous use
Measurement unitslbF, ozF, gF, kgF, N, kN, mN (depending on model)
OutputsUSB / RS-232: Configurable up to 115,200 baud. Auomatic output available up to 250 Hz. Includes Gauge Control Language 2 for full computer control.    Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.   Analog: ±1 VCD, ±0.25% of full scale at capacity,   General purpose: Three open drain outputs, one input.   Set points: Three open drain lines.
Safe overload150% of full scale (display shows "OVER" at 110% and above)
WeightM7-012 - M7-100: 1.0 lb [0.45 kg]   M7-200 - M7-500: 1.2 lb [0.54 kg]
Included itemsCarrying case with chisel, cone, V-groove, hook, flat, extension rod, universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB driver, MESURTM Lite software, MESURTMgauge DEMO software, and user?s guide), and NIST-traceable certificate of calibration with data.
Environmental requirements40 - 100°F, max. 96% humidity, non-condensating
Warranty3 years (see individual statement for further details)

  • Carrying case
    •
  • AC Adapter body with US, EU, or UK prong
    •
  • Battery (inside the gauge)
    •
  • Extension rod
    •
  • Cone
    •
  • Chisel
    •
  • V-Groove
    •
  • Flat
    •
  • Hook
    •
  • Coupling
    •
  • Thread adapter
    •
  • Certificate of Calibration
    •
  • USB Cable
    •
  • Resource CD

    • USB Driver
      •
    • User's Guide
      •
    • MESUR™ Lite Software
      •
    • MESUR™gauge DEMO Software
      •
