Spectra Precision GL622IR Grade Laser
$2,150.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Spectra Precision GL622IR Grade Laser Specs
| Leveling accuracy1,3 | ± 0.5 mm/10 m, 1/16“ @ 100 ft, 10 arc seconds |
| Grade accuracy1,3 | ± 1.0 mm/10 m, 1/8“ @ 100 ft, 20 arc seconds |
| Grade temperature drift sensitivity | ± 0,3 mm / 10 m / 1°C; 1/16” @ 310 ft. @ 1°F |
| Operating diameter1,2 | appr. 800 m (2600 feet) with detector |
| Grade range (Y, X-GL622N/GL622IR) | ± 25% both axes (not simultaneously) |
| Rotation | 300, 600, 750 rpm |
| Laser type | 639 nm (GL622IR: typ.830 nm) |
| Laser class | Class 2 (GL622IR: class 1) |
| Self-leveling range | appr. ± 14° |
| Leveling indicators | LCD indications and LED flashes |
| Radio range (HL760)1,2,4 | up to 150 m (490 ft) |
| Power source | NiMH battery pack |
| Battery life1 | 35 hours NiMH (GL622IR: 40 hours NiMH) |
| Operating temp. | -20°C to 50°C (-4°F to 122°F) |
| Storage temp. | -20°C to 70°C (-4°F to 158°F) |
| Tripod attachments | 5/8 x 11 horizontally and vertically |
| Dust and waterproof | Yes - IP67 |
| Weight | 3.1 kg (6.8 lbs) |
| Low voltage indication | LCD battery indicator |
| Low voltage disconnection | unit shuts off |
| Warranty | 5 Years |
- Includes RC602N Remote
- Includes HL760 Reciever
- Includes Clamp
- Includes NIMH Batteries
- Includes Universal Charger
