Hioki RM3548-50 – Portable DC Resistance Meter (3mΩ to 3MΩ)
$1,190.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Hioki RM3548-50 - Portable DC Resistance Meter (3mΩ to 3MΩ) Specs
| Resistance range | 3 mΩ (3.5000 mΩ display Max., 0.1 μΩ resolution) to 3 MΩ range (3.5000 MΩ display Max., 100 Ω resolution), 10 steps Measurement accuracy: ±0.020 % rdg. ±0.007 % f.s. |
| Testing current | [at 3 mΩ range] 1 A DC to [at 3 MΩ range] 500 nA DC |
| Open-terminal voltage | 5.5 V DC max. |
| Temperature measurement | -10.0 to 99.9°C, accuracy: ±0.50°C (Temperature Sensor Z2002 and RM3548 combined accuracy) |
| Measurement speed | Fixed |
| Display refresh rate | Without OVC: approx. 100ms, With OVC: approx. 230ms |
| Functions | Temperature correction, temperature conversion, offset voltage compensation (OVC), comparator (ABS/REF%), length conversion, judgment sound setting, auto hold, auto power save (APS) |
| Memory storage | Number of recordable data points: (manual/auto) Up to 1,000, (interval) Up to 6,000; Interval: 0.2 to 10.0s (0.2s steps); Acquisition of data from memory: display, USB mass storage (CSV, TXT files) |
| Other functions | Averaging, panel store/panel load, USB communication interface (RM3548 internal memory is recognized as a mass storage device when connected to a PC.) |
| Power supply | LR6 (AA) Alkaline batteries x8, Continuous use: 10 hours (Under our company's conditions), Rated power consumption: 5 VA |
| Dimensions, mass | 192 mm (7.56 in) W x 121 mm (4.76 in) H x 55 mm (2.17 in) D mm, 770 g (27.2 oz) |
| Supplied accessories | Clip type lead 9287-10 x1, Temperature sensor Z2002 x1, LR6 Alkaline battery x8, Instruction manual x1, USB Cable(A-to-mini B type) x1, Strap x1, Extra fuse x1 |
- (1) L2107 Clip type lead
- (1) Z2002 Temperature sensor
- (8) LR6 Alkaline battery
- (1) USB cable (A to Mini B type)
- (1) Strap
- (1) Spare fuse
- (1) Instruction manual
