Instek GOM-805 DC Milli-Ohm meter with Handler / RS-232C / USB Device / GPIB
$723.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Instek GOM-805 DC Milli-Ohm meter with Handler / RS-232C / USB Device / GPIB Specs
| MODEL | GOM-804 |
| Slow | 10 readings / s |
| Fast | 60 readings / s |
| Range / Test current (fixed) | 50mO /1A |
| 50O / 10mA | 500O / 1mA |
| 50kO / 100µA | 500kO / 10µA |
| Accuracy | 50mO : ± (0.1% of reading + 0.02% of range) |
| Resolution | 1µO, 10µO, 100µO, 1mO, 10mO, 100mO, 1O, 10O, 100O |
| Range | -50°C ~399.9°C |
| Accuracy | -10°C ~40°C : 0.3% ± 0.5°C ; Other : 0.3% ± 1.0°C |
| Resolution | 0.1°C |
| -- | Open circuit less than 20mV; For 500mO, 5O, 50O range only |
| DC+/DC- | -- |
| Pulsed | -- |
| PWM | -- |
| Zero | -- |
| USB | Standard |
| RS-232C | Standard |
| HANDLER/SCAN/EXT I/O | Standard |
| GPIB | Option |
| NOTE | Specifications are ensured only for GOM-804/805 at least 30 minute of warm-up time and Operating Temperature Specification: 18~28°C |
| Display | 3.5'(320 x 240) TFT LCD |
| Memory | 20 sets for panel setting |
| Power Source | AC 100 - 240 V, 50/60Hz |
| Comsumption | 25VA (max.) |
| Dimension | 223(W) x 102(H) x 283(D) mm |
| Weight | Approx.4kg(max.) |
- Quick Start Guide x 1
- Power cord x 1
- Test lead GTL-308 x 1
- CD x 1 (complete user manual)
