Extech EX520A – Heavy Duty True RMS Multimeter with CAT IV-600V Safety Rating and High Accuracy

$120.00
In Stock
In Stock
Add to wishlist
Commercial Pricing
Request for Quotations for Bulk Orders
SKU: EXTECH-EX520A-15780
Category:
Brand:

Description

Tech Specs

Specification Name Value
Multimeters Template
Style Hand-Held
Measures AC V Yes
Measures DC V Yes
Measures AC A Yes
Measures DC A Yes
True RMS Yes
Maximum Voltage AC 1000 V
Maximum Voltage DC 1000 V
Maximum Current AC 10 A
Minimum Current AC 0.1 uA (0.00010 mA)
Maximum Current DC 10 A
Minimum Current DC 0.1 uA (0.00010 mA)
Basic Accuracy V DC +/-0.09%
Counts 6000 .
Backlight Yes
Manual/Autoranging Both
Resistance Yes
Frequency Yes
Capacitance Yes
Temperature Yes
Diode Testing Yes
CAT Rating IV
CAT Voltage 600 V
Overload Protector Yes
Low-Pass Filter Yes
Test Equipment General Attributes
Warranty 3 YEARS
Safety Approval CE, CSA, UL
IP Rating IP67
Battery Type 9v

Extech EX520A - Heavy Duty True RMS Multimeter with CAT IV-600V Safety Rating and High Accuracy Specs

StyleHand-Held
Measures AC VYes
Measures DC VYes
Measures AC AYes
Measures DC AYes
True RMSYes
Maximum Voltage AC1000 V
Maximum Voltage DC1000 V
Maximum Current AC10 A
Minimum Current AC0.1 uA (0.00010 mA)
Maximum Current DC10 A
Minimum Current DC0.1 uA (0.00010 mA)
Basic Accuracy V DC+/-0.09%
Counts6000 .
BacklightYes
Manual/AutorangingBoth
ResistanceYes
FrequencyYes
CapacitanceYes
TemperatureYes
Diode TestingYes
CAT RatingIV
CAT Voltage600 V
Overload ProtectorYes
Low-Pass FilterYes
Warranty3 YEARS
Safety ApprovalCE, CSA, UL
IP RatingIP67
Battery Type9v
