Fluke Networks OFP2-100-S-NW OptiFiber Pro Single Mode OTDR V2, without Wi-Fi
$7,604.00
In Stock
Complete single-mode optical fiber attenuation auditing and high-security enterprise network diagnostics reach optimal testing efficiency when utilizing the streamlined Fluke Networks OFP2-100-S-NW OptiFiber Pro V2 module kit. Engineered for tight defense data centers and restricted administrative facilities, this 1310/1550 nm single-mode tool prevents data leak variances via a strict non-wireless configuration layout. It features an automated EventMap visual analysis software platform, an impact-resistant ABS frame layout, and a durable internal calibration framework.
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Fluke Networks OFP2-100-S-NW OptiFiber Pro Single Mode OTDR V2, without Wi-Fi Specs
| Multimode module | Singlemode module |
| Wavelengths | 850 nm +/- 10 nm 1300 nm +35/-15 nm |
| Compatible fiber types | 50/125 µm 62.5/125 µm |
| Event dead zone 1 | 850 nm: 0.5 m typical 1300 nm: 0.7 m typical |
| Attenuation dead zone 2 | 850 nm: 2.5 m typical 1300 nm: 4.5 m typical |
| Dynamic range 3, 5, 6 | 850 nm: 28 dB typical 1300 nm: 30 dB typical |
| Max distance range setting | 40 km |
| Distance measurement range 4, 5, 7, 8, 9, 10 | 850 nm: 9 km 1300 nm: 35 km |
| Reflectance range 4, 5 | 850 nm: -14 dB to -57 dB (typical) 1300 nm: -14 dB to -62 dB (typical) |
| Sample resolution | 3 cm to 400 cm |
| Pulse widths (nominal) | 850 nm: 3, 5, 20, 40, 200 ns 1300 nm: 3, 5, 20, 40, 200, 1000 ns |
| Test time (per wavelength) | Auto setting: 5 sec (typical) |
| Quick test setting: 2 sec (typical) | Quick test setting: 5 sec (typical) |
| Best resolution setting: 2 to 180 sec | Best resolution setting: 5 to 180 sec |
| FaultMap setting: 2 sec (typical), 180 sec (max) | FaultMap setting: 10 sec (typical), 180 sec (max) |
| DataCenter OTDR setting: 1 sec (typical at 850 nm), 7 sec (max) | DataCenter OTDR setting: 20 sec (typical), 40 sec (max) |
| Manual setting: 3, 5, 10, 20, 40, 60, 90, 120, 180 sec | Manual setting: 3, 5, 10, 20, 40, 60, 90, 120, 180 sec |
- (1) Versiv Mainframe
- (1) OptiFiber Pro Singlemode OTDR module
- Shoulder Strap
- USB Interface Cable
- Versiv Open Source Software CD
- AC Charger
- Statement of Calibration
- Getting Started Guides
