Hakko FR-301 – Portable Desoldering Tool
$209.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Hakko FR-301 - Portable Desoldering Tool Specs
| Input Voltage | 120 VAC 50/60 Hz |
| Power Consumption | 140W |
| Temperature Range | 350° - 500°C (660° - 930°F) |
| Tip to Ground Resistance | < 2 ohms |
| Tip to Ground Potential | < 2mV |
| Temperature Stability and Accuracy | Meets or exceeds IPC J-STD-001 |
| Heating Element | Ceramic |
| Vacuum Source | Single-Cylinder Diaphragm Pump |
| Vacuum Pressure | 81 kPa (610mm Hg / 24 in. Hg) |
| Suction Flow | 11 L/min |
| Weight | (w/o cord)1 0.52 kg (1.1 lb.) |
| Nozzles | N61 Series |
| Standard Nozzle | N61-08 (φ1.0mm) |
| Dimensions (L x W x H) (w/o cord) | 226 × 49 x 215 mm (8.9 x 1.9 × 8.5 in.) |
- FR-301 desoldering tool
- Carrying case (C5042)
- Ceramic paper filter (Large) (1 installed, 2 replacement) A5044
- Nozzle wrench (B5106)
- Pre-filter (B5104)
- Iron holder (C5003)
- Cleaning Pin for 1.0mm nozzle (B1087)
- Cleaning Pin for heating element (B1085)
- 1.0mm nozzle, installed (N61-08)
- Instruction manual
