Fluke 9142-E-156 – Low-Temp Field Metrology Well with 9142-INSE
$5,421.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Fluke 9142-E-156 - Low-Temp Field Metrology Well with 9142-INSE Specs
| Temperature Range at 23 °C | 9142 –25 °C to 150 °C (–13 °F to 302 °F) 9143 33 °C to 350 °C (91 °F to 662 °F) 9144 50 °C to 660 °C (122 °F to 1220 °F) |
| Display Accuracy | 9142 ± 0.2 °C Full Range 9143 ± 0.2 °C Full Range 9144 ± 0.35 °C at 50 °C ± 0.35 °C at 420 °C ± 0.5 °C at 660 °C |
| Stability | 9142 ± 0.01 °C Full Range 9143 ± 0.02 °C at 33 °C ± 0.02 °C at 200 °C ± 0.03 °C at 350 °C 9144 ± 0.03 °C at 50 °C ± 0.04 °C at 420 °C ± 0.05 °C at 660 °C |
| Axial Uniformity at 40 mm (1.6 in) | 9142 ± 0.05 °C Full Range 9143 ± 0.04 °C at 33 °C ± 0.1 °C at 200 °C ± 0.2 °C at 350 °C 9144 ± 0.05 °C at 50 °C ± 0.35 °C at 420 °C ± 0.5 °C at 660 °C |
| Radial Uniformity | 9142 ± 0.01 °C Full Range 9143 ± 0.01 °C at 33 °C ± 0.015 °C at 200 °C ± 0.02 °C at 350 °C 9144 ± 0.02 °C at 50 °C ± 0.05 °C at 420 °C ± 0.10 °C at 660 °C |
| Loading Effect (with a 6.35 mm reference probe and three 6.35 mm probes) | 9142 ± 0.006 °C Full Range 9143 ± 0.015 °C Full Range 9144 ± 0.015 °C at 50 °C ± 0.025 °C at 420 °C ± 0.035 °C at 660 °C |
| Hysteresis | 9142 0.025 9143 0.03 9144 0.1 |
| Operating Conditions | 0 °C to 50 °C, 0 % to 90 % RH (non-condensing) |
| Environmental Conditions (for all specifications except temperature range) | ± 1.0 % RH for ± 5 % changes within 20 % RH to 70 % RH |
| RH Resolution | 13 °C to 33 °C |
| Immersion (Well) Depth | 150 mm (5.9 in) |
| Insert OD | 9142 30 mm (1.18 in) 9143 25.3 mm (1.00 in) 9144 24.4 mm (0.96 in) |
| Heating Time | 9142 16 min: 23 °C to 140 °C 23 min: 23 °C to 150 °C 25 min: –25 °C to 150 °C 9143 5 min: 33 °C to 350 °C 9144 15 min: 50 °C to 660 °C |
| Cooling Time | 9142 15 min: 23 °C to –25 °C 25 min: 150 °C to –23 °C 9143 32 min: 350 °C to 33 °C 14 min: 350 °C to 100 °C 9144 35 min: 660 °C to 50 °C 25 min: 660 °C to 100 °C |
| Resolution | 0.01 ° |
| Display | LCD, °C or °F user-selectable |
| Size (H x W x D) | 290 mm x 185 mm x 295 mm (11.4 x 7.3 x 11.6 in) |
| Weight | 9142 8.16 kg (18 lb) 9143 7.3 kg (16 lb) 9144 7.7 kg (17 lb) |
| Power Requirements | 9142 100 V to 115 V (± 10 %) 50/60 Hz, 635 W 230 V (± 10 %) 50/60 Hz, 575 W 9143100 V to 115 V (± 10 %), 50/60 Hz, 1400 W 230 V (± 10 9144 %), 50/60 Hz, 1800 W |
| Computer Interface | RS-232 and 9930 Interface-it control software included |
| Built-in Reference Thermometer Readout Accuracy (4-Wire Reference Probe)† | ± 0.010 °C at -25 °C ± 0.015 °C at 0 °C ± 0.020 °C at 50 °C ± 0.025 °C at 150 °C ± 0.030 °C at 200 °C ± 0.040 °C at 350 °C ± 0.050 °C at 420 °C ± 0.070 °C at 660 °C |
| Reference Resistance Range | 0 ohms to 400 ohms |
| Reference Resistance Accuracy‡ | 0 ohms to 42 ohms: ±0.0025 ohms 42 ohms to 400 ohms: ±60 ppm of reading |
| Reference Characterizations | ITS-90, CVD, IEC-751, Resistance |
| Reference Measurement Capability | 4-wire |
| Built-in RTD Thermometer Readout Accuracy | NI-120: ± 0.015 °C at 0 °C PT-100 (385): ± 0.02 °C at 0 °C PT-100 (3926): ± 0.02 °C at 0 °C PT-100 (JIS): ± 0.02 °C at 0 °C |
| RTD Resistance Range | 0 ohms to 400 ohms |
| RTD Resistance Accuracy‡ | 0 ohms to 25 ohms: ±0.002 ohms 25 ohms to 400 ohms: ±80 ppm of reading |
| RTD Characterizations | PT-100 (385),(JIS),(3926), NI-120, Resistance |
| RTD Measurement Capability | 4-wire RTD (2-,3-wire RTD w Jumpers only) |
| RTD Connection | 4 terminal input |
| Built-in TC Thermometer Readout Accuracy | Type J: ± 0.7 °C at 660 °C Type K: ± 0.8 °C at 660 °C Type T: ± 0.8 °C at 400 °C Type E: ± 0.7 °C at 660 °C Type R: ± 1.4 °C at 660 °C Type S: ± 1.5 °C at 660 °C Type M: ± 1.4 °C at 660 °C Type L: ± 0.7 °C at 660 °C Type U: ± 0.75 °C at 600 °C Type N: ± 0.9 °C at 660 °C Type C: ± 1.1 °C at 660 °C |
| TC Millivolt Range | –10 mV to 75 mV |
| Voltage Accuracy | 0.025% of reading + 0.01 mV |
| Internal Cold Junction Compensation Accuracy | ± 0.35 °C (ambient of 13 °C to 33 °C) |
| TC Connection | Small connectors |
| Built-in mA Readout Accuracy | 0.02 % of reading + 2 mV |
| mA Range | Cal 4-22 mA, Spec 4-24 mA |
| mA Connection | 2 terminal input |
| Loop Power Function | 24 V DC loop power |
| Built-in Electronics Temperature Coefficient (0 °C to 13 °C, 33 °C to 50 °C) | ± 0.005 % of range per °C |
- 9142 Field Metrology Well
- 9142-INSE Insert
- Power Cord
- RS-232 Cable
- User Guide
- Technical Manual CD
- Report Calibration and calibration label. Accredited ISO17025 Calibration
- Well Insulator
- Tongs (Insert removal tool)
