Fluke 9190A-E-P-156 DRY-WELL,ULTRA-COLD,INSRT-E,BLT-IN ELCT, 115V
$16,349.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Fluke 9190A-E-P-156 DRY-WELL,ULTRA-COLD,INSRT-E,BLT-IN ELCT, 115V Specs
| Temperature range at 23 °C | –95 °C to 140 °C (–139 °F to 284 °F) |
| Display accuracy | ± 0.2 °C full range |
| Accuracy with external reference [3] | ± 0.05 °C full range |
| Stability | ± 0.015 °C full range |
| Axial uniformity at 40 mm (1.6 in) | ± 0.05 °C full range |
| Radial gradient | ±0.01 °C full range |
| Loading effect | (with a 6.35 mm reference probe and three 6.35 mm probes) |
| Operating conditions | 0 °C to 35 °C, 0 % to 90 % |
| Environmental conditions for all specifications except temperature range | 13 °C to 33 °C |
| Immersion (well) depth | 160 mm (6.3 in) |
| Well diameter | 30 mm (1.18 in) |
| Heating time [1] | –95 °C to 140 °C: 40 min |
| Cooling time [1] | 23 °C to –90 °C: 80 min |
| Stabilization time [2] | 15 min |
| Resolution | 0.01 ° |
| Display | LCD, °C or °F user selectable |
| Size (H x W x D) | 480 mm x 205 mm x 380 mm (18.8 in x 8.0 in x 14.9 in) |
| Weight | 16 kg (35 lb) |
| Power requirements | 100 V to 115 V (± 10 %) 50/60 Hz, 575 W |
| System fuse ratings | 115 V: 6.3 A T 250 V |
| 4–20 mA Fuse (-P model only) | 50 mA F 250 V |
| Computer interface | RS-232, USB Serial, and 9930 interface-it temperature calibration software included |
| Safety | IEC 61010-1, Installation Category II, Pollution degree 2 |
| Electromagnetic environment | IEC 61326-1: Basic |
| Refrigerants | R32 (Difluoromethane) |
| Built-in reference thermometer readout accuracy (4-wire reference probe) [3] | ± 0.010 °C at –95 °C |
| Reference resistance range | 0 Ω to 400 Ω |
| Reference resistance accuracy [4] | 0 Ω to 42 Ω: ± 0.0025 Ω 42 Ω to 400 Ω: ± 60 ppm of reading |
| Reference characterizations | ITS-90, CVD, IEC-751, resistance |
| Reference measurement capability | 4 wire |
| Reference probe connection | 6-pin din with INFO-CON technology |
| Built-in RTD thermometer readout accuracy | NI-120: ± 0.015 °C at 0 °C |
| RTD resistance range | 0 Ω to 400 Ω |
| Resistance accuracy [4] | 0 Ω to 25 Ω: ± 0.002 Ω |
| RTD characterizations | PT-100 (385), (JIS), (3926), NI-120, resistance |
| RTD measurement capability | 2-wire, 3-wire, and 4-wire RTD with jumpers only |
| RTD connection | 4-terminal input |
| Built-in TC thermometer readout accuracy [5] | Type J: ± 0.70 °C at 140 °C |
| TC millivolt range | –10 mV to 75 mV |
| Voltage accuracy | 0.025 % of reading +0.01 mV |
| Internal cold junction compensation accuracy | ± 0.35 °C (ambient of 13 °C to 33 °C) |
| TC connection | Miniature connectors (ASTM E1684) |
| Built-in mA readout accuracy | 0.02 % of reading + 0.002 mA |
| mA range | Cal 4-22 mA, Spec 4-24 mA |
| mA connection | 2 terminal input |
| Loop power function | 24 V dc loop power |
| Built-in electronics temperature coefficient (0 °C to 13 °C, 33 °C to 50 °C) | ± 0.005 % of range per °C |
- Report of Calibration with calibration label. Accredited ISO17025 Calibration
