Comet T5140 – CO2 Concentration Transmitter with 4-20mA Output, Built-in Carbon Dioxide Sensor
$468.00
In Stock
Industrial ventilation control loops reach absolute stability when using the Comet T5140 current loop carbon dioxide transmitter. This single-channel monitoring tool features an integrated NDIR gas sensor tracking a 0 to 2000 ppm concentration window with a precision accuracy profile of ±50 ppm. It converts measured values into a standard 4 to 20 mA analog output framework safely.
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Comet T5140 - CO2 Concentration Transmitter with 4-20mA Output, Built-in Carbon Dioxide Sensor Specs
| Brand | N/A |
| Technical Parameters | Value |
| Output | 4-20mA |
| Measured Value | CO2 |
| Construction Type | Ambient Air |
| Design | Industrial |
| Temperature Measuring Range | to °C |
| Relay Output | No |
| Two-State Input | No |
| Lcd Display | Yes |
| PoE | No |
| Range of CO2 concentration measurement | 0 to 2000 ppm |
| Accuracy of CO2 concentration measurement | ±(50ppm +2% from reading) at 25°C and 1013hPa |
| Temperature operating range | -30 to +60°C |
| IP protection | IP30 |
| Power | 9-30Vdc |
| Dimensions | 88.5 x 94 x 39.5 mm (W x H x D) |
| Weight | approximately 145g |
| Warranty | 3 years |
- T5140 sensor
- Traceable calibration certificate
- Quick start manual
