FLIR E96-24-NIST – Advanced Thermal Camera with MSX, 30Hz, with 24 Degrees Lens and NIST Calibration
$16,989.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Description
Tech Specs
| Specification Name | Value |
| Thermal Imagers/Building and Industrial Thermal Imagers Template | Detector Size 640 x 480 Sensor |
| Temperature Range Max | 1500 F |
| Temperature Range Min | -4 F |
| Image Frequency | 30 Hz |
| Field of View | 24×18 Degrees |
| Screen Size | 4 IN |
| IR/Overlay Fusion Image | Yes |
| Video Output | Yes |
| Focus | Adjustable |
| Laser Spot | Yes |
| Picture in Picture | Yes |
| Video Recording | Yes |
| Moveable Spots | Yes |
| Touch Screen Display | Yes |
| Minimum Focus Distance | 0.15 M |
| Accuracy | ?2?C (?3.6?F) or ?2% of the reading |
| Battery operating time Continuous | 2.5 HR |
| Camera Light | Yes |
| IR Digital Zoom | Yes |
| Voice Annotation | Yes |
| Intrinsically Safe | No |
| Test Equipment General Attributes | Unique Features 24? Lens, FLIR MSX Technology, FLIR Inspection Route, FLIR Thermal Studio Pro and Flir Route Creator 3-month subscription offer |
| Safety Approval | CSA, UL |
| Interfaces I/O | Bluetooth, Wifi, USB |
| Storage | SD Card |
| IP Rating | IP54 |
| Product Weight | 2.2 LBS |
| Product Height | 4.4 IN |
| Product Length | 11 IN |
| Product Width | 4.6 IN |
| Shipping Weight | 12.8 LBS |
| Data Logging | Yes |
| ECCN Number | 6A003.b.4.b |
| Calibration Included | NIST Calibration |
| Battery Type | Li-ion |
| Power Supply Voltage | Battery Powered |
| Country of Origin | Estonia |
| Shipping Height | 14.6 IN |
| Shipping Length | 19.7 IN |
| Shipping Width | 7.5 IN |
FLIR E96-24-NIST - Advanced Thermal Camera with MSX, 30Hz, with 24 Degrees Lens and NIST Calibration Specs
| Thermal Imagers/Building and Industrial Thermal Imagers Template | Detector Size 640 x 480 Sensor |
| Temperature Range Max | 1500 F |
| Temperature Range Min | -4 F |
| Image Frequency | 30 Hz |
| Field of View | 24x18 Degrees |
| Screen Size | 4 IN |
| IR/Overlay Fusion Image | Yes |
| Video Output | Yes |
| Focus | Adjustable |
| Laser Spot | Yes |
| Picture in Picture | Yes |
| Video Recording | Yes |
| Moveable Spots | Yes |
| Touch Screen Display | Yes |
| Minimum Focus Distance | 0.15 M |
| Accuracy | ?2?C (?3.6?F) or ?2% of the reading |
| Battery operating time Continuous | 2.5 HR |
| Camera Light | Yes |
| IR Digital Zoom | Yes |
| Voice Annotation | Yes |
| Intrinsically Safe | No |
| Test Equipment General Attributes | Unique Features 24? Lens, FLIR MSX Technology, FLIR Inspection Route, FLIR Thermal Studio Pro and Flir Route Creator 3-month subscription offer |
| Safety Approval | CSA, UL |
| Interfaces I/O | Bluetooth, Wifi, USB |
| Storage | SD Card |
| IP Rating | IP54 |
| Product Weight | 2.2 LBS |
| Product Height | 4.4 IN |
| Product Length | 11 IN |
| Product Width | 4.6 IN |
| Shipping Weight | 12.8 LBS |
| Data Logging | Yes |
| ECCN Number | 6A003.b.4.b |
| Calibration Included | NIST Calibration |
| Battery Type | Li-ion |
| Power Supply Voltage | Battery Powered |
| Country of Origin | Estonia |
| Shipping Height | 14.6 IN |
| Shipping Length | 19.7 IN |
| Shipping Width | 7.5 IN |
- Infrared camera with lens
- Hard transport case
- Power supply for battery charger
- Power supply, 15 W/3 A
- Printed documentation
- SD card (8 GB)
- USB 2.0 A to USB Type-C cable, 1.0 m
- USB Type-C to HDMI adapter, standard specification UH311
- USB Type-C to USB Type-C cable (USB 2.0 standard), 1.0 m
- Front protection fastener, hand strap brackets left/right, screws
- Torx T10 wrench
- Carabiner hook
- Front protection
- Hand strap, Lanyard strap, Lens cap strap, Wrist strap
- Battery (2 ea)
- Battery charger
- FLIR Thermal Studio Starter
- Lens cap, front
- Lens cap, front and rear (only for extra lenses)
