Additel ADT875-1210-ES-110V – Thermocouple Calibration Furnace

$9,346.00
In Stock
In Stock
Add to wishlist
Commercial Pricing
Request for Quotations for Bulk Orders
SKU: Additel-ADT875-1210-ES-110V
Category:
Brand:

Additel ADT875-1210-ES-110V - Thermocouple Calibration Furnace Specs

875-1210878-1210
Temperature Range100°C to 1210°C
±1.2°C @ 100°C±1.0°C @ 100°C
±1.2°C @ 300°C±1.0°C @ 300°C
±1.2°C @ 600°C±1.0°C @ 600°C
±1.6°C @ 900°C±1.2°C @ 900°C
±2.0°C @ 1210°C±1.5°C @ 1210°C
Stability±0.1°C
Axial Uniformity (20mm zone)±0.6°C @ 100°C
±0.9°C @ 300°C±0.6°C @ 300°C
±1.2°C @ 600°C±0.8°C @ 600°C
±1.5°C @ 900°C±1°C @ 900°C
±1.5°C @ 1210°C±1°C @ 1210°C
Radial Uniformity±0.2°C @ 100°C
±0.3°C @ 300°C±0.3°C @ 300°C
±0.4°C @ 600°C±0.4°C @ 600°C
±0.8°C @ 900°C±0.6C @ 900°C
±1°C @ 1210°C±0.8°C @ 1210°C
Loading Effect±0.5°C
Environmental Conditions8°C to 38°C guaranteed accuracy
Storage Conditions-20°C to 60°C
Immersion DepthXR style inserts = 138 mm (5.43")
Insert Size - OD24.8 mm (0.98 inches)
Heating Time50 min: 23°C to 1210°C
Cooling Time50 mins:1210°C to 300°C 50 mins: 300°C to 50°C
Typical Time to Stability15 min
Resolution0.01°C
Units°C, °F, and K
Display6.5 in (165 mm) color touch screen
Size (H x W x D)345 x 170 x 330 mm (13.6 x 6.7 x 13.0 in)
Weight10.6 kg (23.4 lbs)
Power Requirements115 V AC (±10%) or 230 V AC (±10%), switchable, 45-65 Hz, 580 W
Mechanical TestingVibration: 2 g (10-500 Hz) , 30 min for 2 sides
CommunicationUSB A, USB B, RJ45, WiFi, Bluetooth
LocalizationEnglish, Chinese, Japanese, Russian, German
Warranty1 year
875-1210878-1210
TC Measurement ChannelsPatented TC terminals:
TC Measurement Accuracy Type K Ch. 1-4 (excluding sensor)±0.182°C @ 100°C
±0.182°C @ 100°C±0.172°C @ 100°C
±0.266°C @ 300°C±0.236°C @ 300°C
±0.310°C @ 600°C±0.251°C @ 600°C
±0.397°C @ 900°C±0.304°C @ 900°C
±0.517°C @1210°C±0.382°C @ 1210°C
TC Range€“75 mV to 75 mV (UUT Channels 1-4)
TC Resolution0.0001 mV, Input Impedance < 10Ω
TC Voltage Accuracy0.02% RD + 8μV (ch. 1-4)
0.01% RD + 2μV (ref ch.)0.005% RD + 2μV (Ref ch.)
Internal CJC Accuracy±0.35°C (ch. 1-4)
±0.25°C (ref ch.)±0.20°C (ref ch.)
Current Range€“30 mA to 30 mA
Current Accuracy±(0.02% of rdg+ 2μA)
0.001 V; Input impedance: > 1M 1MΩ0.0001V
DC 24V Output24 V ± 10%, MAX 60 mA
Hart CommunicationOptional (ADT875PC and ADT878PC Models)
"Temperature Coefficient 0°C to 8°C and 38°C to 50°CTC Readouts: ±5 ppm FS/°C
Switch TestMechanical or Electrical - Channels 1 and 2 only
DocumentationUp to 1,000 tasks which store up to 10 results each containing as found and as left data. Snap shot feature allows for screen captures. Records auto step and ramp functions
TC TypeTEMP (°C)
875875
K (CH1-CH4)100
300±0.266
600±0.310
900±0.397
1210±0.517
N (CH1- CH4)100
300±0.270
600±0.309
900±0.368
1210±0.455
E (CH1- CH4)100
300±0.153
600±0.210
900±0.291
1000±0.297
L (CH1- CH4)100
300±0.271
600±0.308
900±0.522
U (CH1- CH4)100
300±0.189
600±0.227
J (CH1- CH4)100
300±0.197
600±0.256
900±0.281
1200±0.414
S (CH1-CH4)100
300±0.924
600±0.888
900±0.868
1210±0.865
R (CH1- CH4)100
300±0.869
600±0.804
900±0.771
1210±0.766
B (CH1- CH4)250
300±2.645
600±1.409
900±1.049
1210±0.905
T (CH1- CH4)100
300±0.191
400±0.217
S (EXT. REF)100
300±0.242
600±0.249
900±0.258
1210±0.266
R (EXT. REF)100
300±0.228
600±0.227
900±0.230
1210±0.240

  • Calibration Furnace and selected Insert & insulator
    •
  • Power adapter
    •
  • USB Cable
    •
  • Insert removal tool
    •
  • Accredited Calibration Certification
    •
  • Manual
