Fluke 566 Infrared Thermometer
$315.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Fluke 566 Infrared Thermometer Specs
| Infrared temperature range | -40 °C to 650 °C (-40 °F to 1202 °F) |
| Infrared accuracy | 0 °C (32 °F): ± 1 % or ± 1.0 °C (± 2.0 °F), whichever is greater |
| Display resolution | 0.1 °C / 0.1 °F |
| Infrared spectral response | 8 μm to 14 μm |
| Infrared response time | < 500 msec |
| Thermocouple Type-K input temperature range | -270 °C to 1372 °C (-454 °F to 2501 °F) |
| Thermocouple Type-K input accuracy | -270 °C to -40 °C: ± (1 °C + 0.2 °/1 °C) (-454 °F to -40 °F: ± (2 °F + 0.2 °/1 °F)) -40 °C to 1372 °C: ± 1 % or 1 °C (-40 °F to 2501 °F: ± 1 % or 2 °F), whichever is greater |
| D | S (distance to measurement spot size): 30:1 |
| Laser sighting | Single-point laser < 1 mw output Class 2 (II) operation, 630 nm to 670 nm |
| Minimum spot size | 19 mm (0.75 in) |
| Emissivity adjustment | By built-in table of common materials or digitally adjustable from 0.10 to 1.00 by 0.01 |
| Data storage with Date/Time stamp | 20 points |
| PC Interface and cable | None |
| Hi/Low alarms | Audible and two-color visual |
| Min/Max/Avg/Dif | Yes |
| Display | Dot matrix 98 x 96 pixels with function menus |
| Backlight | Two levels, normal and extra bright for darker environments |
| Trigger lock | Yes |
| Switchable Celsius and Fahrenheit | Yes |
| Power | 2 AA/LR6 Batteries |
| Battery life | If used continuously: laser and backlight on,12 hours; laser and backlight off, 100 hours |
| Operating temperature | 0 °C to 50 °C (32 °F to 122 °F) |
| Storage temperature | -20 °C to 60 °C (-40 °F to 140 °F) |
| Bead thermocouple Type-K range | -40 °C to 260 °C (-40 °F to 500 °F) |
| Bead thermocouple Type-K accuracy | ± 1.1 °C (2.0 °F) from 0 °C to 260 °C (32 °F to 500 °F), typically within 1.1 °C (2.0 °F) from -40 °C to 0 °C (-40 °F to 32 °F) |
- Thermocouple K Bead Probe
- Durable Hard Case
- 2 AA Batteries
- Getting Started guide in six languages
- User’s Manual on CD in six languages (English, Spanish, French, German, Portuguese, and Simplified Chinese)
- 2-year Warranty
