Rigol DSA705 Spectrum Analyser 500MHz
$682.00
In Stock
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
Rigol DSA705 Spectrum Analyser 500MHz Specs
| Model | DSA705 |
| Frequency range | 100 kHz to 500 MHz |
| Frequency resolution | 1 Hz |
| Reference frequency | 10 MHz |
| Accuracy | ±[ (time since last calibration × aging rate) + temperature stability + calibration accuracy] |
| Initial calibration accuracy | <1 ppm |
| Temperature stability | 0° to 50° , reference to 25° <2 ppm |
| Aging rate | <2 ppm/year |
| Marker resolution | span/ (number of sweep points - 1) |
| Marker uncertainty | ±(frequency indication × reference frequency accuracy + 1% × span + 10% × resolution bandwidth + marker resolution) |
| Resolution | 1 Hz, 10 Hz, 100 Hz, 1 kHz, 10 kHz, 100 kHz |
| Uncertainty | ±(frequency indication × reference frequency accuracy + counter resolution) |
| Range | 0 Hz, 100 Hz to maximum frequency of instrument |
| Uncertainty | ±span/ (number of sweep points - 1) |
| 20° to 30° , fc = 500 MHz | 20° to 30° , fc = 1 GHz |
| 10 kHz | <-80 dBc/Hz |
| 100 kHz | <-100 dBc/Hz (typ.) |
- PreAmplifier
- Instrument Quick Guide
- Power Cord
- NIST calibration certificate for the DSA705
