Terahertz TIA-952-FC InGaAs, 30 KHz to 800 MHz O/E Converter with FC Fiber Interface
$618.00
In Stock
High-sensitivity physical layer monitoring across wide spectral regions is fully optimized via the Terahertz TIA-952-FC diagnostic block. This InGaAs instrumentation assembly handles a 30 kHz to 800 MHz frequency range, processing incoming laser signals through a secure, threaded FC fiber optic interface. It translates optical data streams down to switchable 500 V/W or 2500 V/W conversion gains for clear digitizer reading routines.
In Stock
Commercial Pricing
Request for Quotations for Bulk Orders
| TIA-952 Specifications | |
| Detector Type | Large area InGaAs |
| Analog Signal Bandwidth (-3 dB) | 30 KHz to 800 MHz, Low gain, 30 KHz to 300 MHz High Gain |
| Selectable Responsivity Settings | 500 V/W or 2500 V/W @ 1550 nm when terminated in a 50 Ohm Load |
| Maximum Linear Input Power | 2 mW |
| Max Input Power Without Damage | 15 mW |
| Spectral Response | InGaAs: 850 - 1700 nm |
| Output Impedance | 50 Ohms |
| Output Connector | Male BNC |
| Fiber Optic Connector | Specify FC or ST |
| Input Numerical Aperture | 0.29 |
| Input fiber Accommodated | 9um Single mode or 50/125 & 62.5/125um multi-mode |
| Output Offset Voltage | N/A Volts |
| Noise Level | 9.5 pW/ root-Hz at peak responsivity |
| Maximum Output Voltage | Low gain, 2.0 V pk-pk, High Gain 4 V pk-pk, (Into 50 Ohms) |
| Power Requirements | Supplied wall-mount universal power supply |
| Wall-mount Supply Power Requirements | 90-260VAC, 50 - 60 Hz, 16 VA Max. |
| Mains Connectors Supplied | North America, British, Continental Europe, Australian |
| Dimensions ( mm ) | 30.5 W x 63 L x 33 H |
| Weight | (0.16 Kg) |
| LED Annunciators Provided | Power On |
| Operating Temperature Range | 0 - 40 C |
| Standard Warranty | Two Years, Component and Workmanship, 30 Satisfaction Guarantee |
| Accessories Supplied | Transit Case, Universal Power Supply and Manual |
- Transit Case
- Universal Power Supply
- Manual
